Model
WGV series
Technical specifications:
| Parameter | Specifications |
|---|---|
| Gate material | Stainless steel/aluminum alloy |
| Drive unit | Hoist/reduction motor/stepper motor |
| Protection level | IP65 |
| Installation method | Front attached wall type/door trough type |
| Opening sensor | Opening detection/water level detection (built-in optional) |
| Power supply | Solar / battery |
| Voltage/power consumption | 12V/30W |
| Working water temperature | 1-50℃ |
| Control Method | WEB/APP |
| Remote data transfer | DNP3,modbus TCP/IP,OPC |
| Supporting agreement | Etherner IP,DNP3,Modbus RTU,Modbus TCP/IP,RS-23 |
